Thanks guys
Here are a couple photo's, looking down view.
Old OEM bars are on top of the granola bar, the tape shows the reach back
and distance to the front of the seat nose. I had to tape the bars to hold them in place.
Image 20220708-151526 in Nvreloader's images album
ibb.co
Image 20220708-151553 in Nvreloader's images album
ibb.co
UPDATED INFO
Here is an update to these new bars I just added to my Wart Hog bike,
I almost made a Bo Bo,
I had to add several pieces of rubber shim stock to several of the wrap a round bar clamps that hold these items onto the bars, the diameter was smaller than the OEM bars, due to the taper from the clamp area.
The OEM bars (approximately Salsa type bars) had a longer fatter straight section leaving the clamp area, before the first bend in the bar ends etc.
The new Granola bars has a very short straight section (not enough room) for all the items I wanted to attach to these bars before the bends started, I had to shim the display and extra accessory bar I added, due to the reduced diameter in the Granola bar.
See this diagram/site to impose different bars over each other to see the differences, select the Velo Ganola bar and then select the Rivendell Bosco and you can see the difference.
It is too bad that more handle bars are not included, it would make selections of handle bars so much easier.
https://whatbars.com/
HTH's
Your thoughts and suggestions.........
Tia,
Don
