FlatSix911
Well-Known Member
- Region
- USA
- City
- Silicon Valley
Correct... you are almost there!
Keep practicing to increase your cadence to the 85 -95 range.
Specialized Turbo Creo 28mph Electric Road Bike
- Thread starter Admin
- Start date
Correct... you are almost there!
Keep practicing to increase your cadence to the 85 -95 range.
sapidus
New Member
I've been considering purchasing a SKS Anywhere Bicycle Attachment Water Bottle Mount with Top Cage Bottle Holder (or some variant) to solve this problem. Readily available online and seems to get good reviews. Haven't tried it yet.
Papadevo
New Member
Wolf tooth components makes a double water bottle holder that I am trying out. I also bought their “b-rad2” to move the bottle location. Works OK, but needs some tweaks.
B-RAD SYSTEM
Be rad with the B-RAD System, the ultimate Bottle Relocation and Accessory Device. Mount your bottles away from inconvenient rear shocks, add storage room for tools or tubes below a bottle cage, and provide space for a second bottle on sufficiently-long downtubes—all with one patented design...
www.wolftoothcomponents.com
Sean McIllwain
New Member
The new Creos have a “Road Remote”. Anyone know what this is?
sapidus
New Member
Really anywhere you want there's space, as far as I can tell. You can google it and see a few photos of what others have done. I was thinking about trying under the top tube. There's also a variant that may work well on the seat post that's on Amazon as well. There are other designs out there from other manufacturers that do similar, you'd just need to look around and see what best fits your needs if you go this route.
"
SKS Bottle Cage Adapter:
Quench your thirst anyway you want with the SKS bottle cage adapter. It mounts a water bottle cage to your seatpost, stem, top tube or anywhere else on your bike. Adjust the angle to your liking, insert your water bottle and you're ready to go.
- Perfect for frames without water bottle mounts
- Angle adjustment for optimal alignment
- Quick-release mount provides a secure fit
- Durable nylon and plastic construction
- Fits 0.5 -- 1.5" tubing
sapidus
New Member
I asked about this is in a seperate thread yesterday. Haven't heard anything back yet. Hoping it's something similar to the DIY remote control others have posted about and it's backward compatible . The lack of the ability to change power levels on the handlebar is the main complaint I have with the Creo.
FlatSix911
Well-Known Member
- Region
- USA
- City
- Silicon Valley
FlatSix911
Well-Known Member
- Region
- USA
- City
- Silicon Valley
I use a similar adjustable post clamp with a magnetic twist-lock bottle.
Amazon.com : Fidlock Twist Bottle 450 Set- Bike Water Bottle Holder with Attached Bottle - Cage Free Magnetic Mount - Smoke : Sports & Outdoors
Amazon.com : Fidlock Twist Bottle 450 Set- Bike Water Bottle Holder with Attached Bottle - Cage Free Magnetic Mount - Smoke : Sports & Outdoors
smile.amazon.com
UPDATE: I just finished a review for the Turbo Creo SL Comp Carbon models here, which includes a full list of specs and video with ride footage! I'm very impressed with the bike and love the new SL 1.1 motor system... it only weighs ~4lbs but provides a surprising amount of zip and power.
Specialized reached out to me earlier this month with some news about their upcoming Turbo Creo SL, which is a high speed electrified road bicycle with the tagline "it's Julian, only faster". For those who aren't familiar with Julian Alaphilippe, he's a celebrated French road cyclist and cyclocross athlete who is renowned for his climbing ability and endurance. So the idea here is that the new Creo ebike will help you climb like a pro, and maybe even do it faster
Name: Specialized Turbo Creo
Marketing Intro: We’re going to flatten your climbs. We’re going to make you laugh at headwinds, ride farther, and go faster than you ever imagined. That’s what our first Turbo road bike is all about. Because, let’s be honest, riding faster is just more fun. Turbo Creo SL—It’s You, Only Faster.
Marketing Overview: The Turbo Creo SL isn’t just the lightest e-bike in its class, it’s literally kilograms lighter than the competition at just 12.2kg (26.89lb) for the S-Works Creo SL. We made the frame out of our FACT 11r carbon, and we designed it to handle like a Tarmac to inspire dancing on the pedals and diving into corners. And with the Future Shock 2.0, and its adjustable damper, we suspend you, not the bike to deliver more control, confidence, and comfort.
We launched Turbo seven years ago, and since then, we’ve been relentless in our pursuit of the perfect e-bike—bikes that feel like you, only faster. Since there wasn’t a motor and system on the market for a performance road bike that we were satisfied with, we developed our own. Designed in California and engineered in Switzerland (the heart of the e-bike revolution), the new Specialized SL 1.1 represents the ideal performance e-road bike motor. It’s based on a decade of research, development, and ride testing, and it features the perfect combination of power, weight, size, range, and ride quality, so it delivers the consistent power in the natural cadence that riders need. In order to build a performance e-road bike, all of these features needed to come together to deliver a true performance road bike experience.
Ultralight and whisper quiet, the Specialized SL 1.1 motor doubles your effort with silky smooth power delivery—power that feels like it’s straight from your legs. No unnatural power curve, lurching, or motor jumps. It delivers up to 240 watts of power that are in sync with your cadence all the way to 28 mph for real-world road riding. And when you want to pedal unassisted, there’s no drag holding you back.
With up to 80 miles of range from the internal battery alone, the Turbo Creo SL lets you enjoy the power, not worry about the range. Our Range Extender, included with the S-Works build and available aftermarket on other models, provides up to 40 additional miles of mountain-flattening power. The internal battery offers 320Wh, while the Range Extender is a 160Wh battery. The Turbo Creo SL’s internal battery can be charged in as little as 2 hours and 35 minutes. Every rider and every ride are different, so we created a Turbo Creo SL Range Calculator to help you determine exactly how far you ride.
Our Mission Control app has logged millions of miles because it offers an intuitive and seamless way to unleash your Turbo. This is a ride app you’ll actually use. Each of the motor’s three assisted riding modes can be tuned almost infinitely for both peak and sustained power delivery. Mission Control can even manage battery power automatically with Smart Control. Just tell it how far or how long you want to ride, and it will ensure you have the battery power to get there. It can record your ride, send it to third-party apps, and it even has an integrated power meter that can send your power numbers to an ANT+ head unit. While seamless connectivity comes standard with the Creo SL, connecting with Mission Control is always optional. The Turbo Connect Unit on the top tube gives you all the control you need to ride.
Our Turbo Creo SL EVO build takes the bike’s revolutionary e-road performance and creates incredible new opportunities for adventure and exploration. This versatile build adds 38mm Pathfinder tires, flared Adventure Gear Hover bars, and a dropper post for long gravel rides, bikepacking, and venturing into the unknown.
The Turbo Creo SL ushers in the era of the performance e-road bike, and our S-Works Creo SL Founder’s Edition celebrates this with an incredible build at just 11.9kg. A host of special touches, including gold foil graphics, a numbered Founder’s Edition plaque on the chainstay, and a custom Founder’s Edition SL Kit make this very limited-edition bike an instant classic.
View attachment 35437View attachment 35438View attachment 35439View attachment 35440View attachment 35441View attachment 35442View attachment 35443View attachment 35444View attachment 35445
Frequently Asked Questions:
WHEN CAN RIDERS GET A TURBO CREO SL?
The Turbo Creo SL will launch globally on July 16th, but only be available in nine markets initially—USA, Germany, Austria, Switzerland, Italy, France, Spain, UK, and the Netherlands—with availability globally in October. Our Founder’s Edition, however, will be available for preorder globally on July 16th.
WHAT WERE THE MAIN GOALS WHEN DEVELOPING THE SPECIALIZED SL1.1 MOTOR AND BATTERY SYSTEM?
The new Specialized SL 1.1 motor represents the ideal performance e-road bike motor, based on a decade of research, development, and ride testing. It features the perfect combination of power, weight, size, range, and ride quality. In order to build a performance e-road bike, all of these features needed to come together to deliver a true performance road bike experience.
HOW MUCH DOES THE MOTOR WEIGH?
At just 1.95kg, the SL 1.1 Motor is essentially half the weight of other crank-based motors. To help achieve this light overall weight, the motor casing is made of magnesium.
HOW MUCH POWER DOES THE NEW MOTOR OUTPUT?
Our SL1.1 motor amplifies rider power up to 240 watts and 35Nm of both peak and sustained power. We tuned our motor to deliver constant, strong support across a wide cadence range for a very natural feel while pedaling.
HOW MANY RIDING MODES ARE THERE AND HOW MUCH ASSIST DO THEY OFFER?
There are three assisted riding modes: ECO, SPORT, and TURBO. ECO matches your effort up to 30% of the motor’s power, SPORT matches your effort up to 60% of the motor’s power, and TURBO matches your effort to 100% of the motor’s power—or 240watts. All three assist modes can be tuned almost infinitely to personalize power levels via our Mission Control App. There is also an unassisted riding mode when no power from the motor is desired.
DO ALL THE MODELS HAVE THE SAME RANGE? WHAT IS IT?
Yes. All models use the same Specialized SL1.1 motor and 320Wh internal battery. Range varies with use, but you can expect up to 130 kilometers (80 miles) of range using ECO mode. With a Range Extender (included with the S-Works and Founder’s Edition models and available aftermarket on other models) another 65 kilometers (40 miles) of range can be added.
IS A RANGE EXTENDER INCLUDED WITH EVERY TURBO CREO SL?
The 160Wh Range Extender comes standard with the S-works and two Range Extenders are included on the Founder’s Edition models. For other models, the Range Extender (adding another 65 kilometers / 40 miles of riding) will be available aftermarket and is the perfect tool to extend your Turbo Creo SL rides even farther.
HOW DOES THE RANGE EXTENDER ATTACH TO THE TURBO CREO SL?
While the Range Extender fits in a normal water bottle cage, we recommend using the Specialized Z-Cage along with the included band for increased security—especially on rougher terrain.
WHAT IMPACTS THE RANGE AND HOW CAN I GET THE MOST DISTANCE POSSIBLE?
There are many variables that influence range. The rider’s weight, fitness, and position on the bike, as well as the bike build, bike weight, tire choice, and tire pressure all impact range. Several environmental influences, such as road conditions, elevation, and weather can impact range as well. The less motor support you require, the longer the battery will last. Riding in ECO mode will generally provide the longest battery life. Our Turbo Range Calculator helps riders predict the range they can expect given certain key metrics.
WHAT MAKES THE TURBO CREO SL SO MUCH LIGHTER THAN THE OTHER BOTTOM-BRACKET-BASED E-ROAD BIKES?
The Turbo Creo SL’s FACT 11r carbon frame combines with the lightweight SL1.1 motor, a magnesium housing, a battery integrated into the frame, and thoughtful builds to create the lightest production e-road bike with a bottom bracket motor in the world.
WHAT IS THE TURBO CREO SL’S Q-FACTOR?
The Turbo Creo SL’s Q-Factor (the distance between crankarms) is 181mm.
HOW MUCH TIRE CLEARANCE DOES THE TURBO CREO SL HAVE?
The Turbo Creo SL has clearance for 42mm tires with 700C rims. With fenders, there’s still clearance for 38mm tires.
CAN I USE 650B WHEELS WITH THE TURBO CREO SL?
Yes. The Turbo Creo SL is compatible with 650b wheels and up to a 47mm tire. Keep in mind the Turbo Creo SL uses 12x110mm front hub spacing and 12x148mm rear spacing.
IS THE TURBO CREO SL EXPERT EVO A DIFFERENT FRAME?
No, it’s the same FACT 11r frame and fork as the other Turbo Creo SL Carbon models, just with an adventure-ready build.
CAN THE TURBO CREO SL’S FIRMWARE BE UPDATED?
The Turbo Creo SL firmware can easily be updated at your local Turbo dealer through Turbo Studio, our retailer service platform. Once connected, the bike automatically checks for the latest software versions available and installs them if needed.
HOW MUCH MOTOR TUNING ABILITY DOES THE MISSION CONTROL APP HAVE?
With the Mission Control App, you can tune the level of assist almost infinitely (both peak power and sustained assistance) for each of the three ride assist levels: ECO, SPORT, and TURBO. Our Mission Control App allows you to fully customize your Turbo Creo SL motor to your personal needs and riding preferences. Of course, we only allow the rider to tune the motor and its behavior within the given speed limits in their respective country. We do not allow riders to tune the motor beyond the legally allowed speed setting.
HOW DOES SMART CONTROL WORK?
Using the Smart Control feature of our Mission Control App enables you to enter how far, or how long, you want to ride, as well as how much battery you would like to have left at the end of your ride. Smart Control then takes care of all battery management to reach those targets. It does this with a smart algorithm that checks the bike’s status every 10 seconds. Keep in mind, with Smart Control initiated on the app, assistance modes cannot be altered via the TCU on the bike’s top tube. Riding with no assistance means you’re not getting any motor support, but that the system is still on and recording/sharing data to display on apps or ANT+ enabled devices.
HOW DOES THE TURBO CONTROL UNIT ON THE BIKE’S TOP TUBE WORK?
The Turbo Control Unit has two buttons and a battery level display. The bottom button is used to turn the bike on, while the top button is used to select one of the three assistance levels—or to ride with no assistance. Quickly push the button to cycle through different modes—1/3 blue circle is ECO, 2/3 blue circle is SPORT, and full blue circle is TURBO. Press and hold the button until all blue lights turn off to ride with no assistance.
CAN THE TURBO CREO SL USE A 2X FRONT CRANK?
No. The SL1 motor is only designed for a 1x setup. Simplicity is key for us. The motor and the wide 1x drivetrain provide plenty of range for all kinds of riders.
HOW MANY SIZES ARE AVAILABLE FOR THE TURBO CREO SL?
The Turbo Creo SL comes in six sizes: XS, SM, MD, LG, XL, and XXL. These sizes are equivalent to 49, 52, 54, 56, 58, and 61cm frames.
HOW IS THE TURBO CREO SL CHARGED?
Included with every Turbo Creo SL is a Specialized 48V charger that plugs into a port on the bike’s seat tube, just above the bottom bracket. The Range Extender is charged with the same charger. After plugging in your charger, it will take five seconds for the TCU to light-up and indicate charging. When all blue bars are illuminated, the bike is fully charged. A green LED on the charger indicates “standby,” while a steady red light indicates “charging.” S-Works bikes and Founder’s Edition bikes will ship with a “Y” cable that allows both to be charged simultaneously.
HOW LONG DOES IT TAKE TO CHARGE THE TURBO CREO SL?
You can expect your Turbo Creo SL’s internal battery to charge from 3% to 100% in approximately 2 hours and 35 minutes. A Range Extender will charge from 3% to 100% in approximately 3 hours and 20 minutes. Both the internal and Range Extender batteries will charge from 3% to 100% in approximately 3 hours 20 minutes with a “Y” cable.
CAN THE INTERNAL BATTERY BE REMOVED FOR CHARGING?
The Turbo Creo SL’s internal battery is fully integrated into the frame. It is intended to be charged in the frame. In order to get the battery out of the frame, you need to remove the motor first. It’s this kind of integration that allows the Turbo Creo SL to be so light.
If you want to fly with your Turbo Creo SL, the internal battery needs to be removed. You can carry a Range Extender in your carryon and when you arrive at your location, you can ride the Turbo Creo SL with just the Range Extender.
WHAT HAPPENS IF THE BATTERY FALLS BELOW 20%?
When the battery falls below 20% charge, the Turbo Creo SL will automatically enter ECO mode to preserve the remaining battery life. At this point, the riding modes cannot be changed until the battery has been recharged.
WHEN A RANGE EXTENDER IS USED, WHICH BATTERY IS USED FIRST? THE RANGE EXTENDER OR THE INTERNAL?
When using a Range Extender, the default setting is for the Range Extender and Internal Battery to be drained simultaneously. By using Mission Control, however, the protocol can be changed to drain the Range Extender first.
WHAT TYPE OF GEOMETRY DOES THE TURBO CREO SL HAVE?
All Turbo Creo SL’s have our Open Road geometry to provide nimble handling with stable steering and confidence at speed. This also gives the Turbo Creo SL much of its versatility, ably transitioning from a twisting road descent to a long gravel road.
Here's a couple of photos posted on the Facebook Creo page, and two (2) different descriptions and PN's. Apparently one button increases assist mode, and one button decreases assist mode.
Quote 1:
"Brett Cruickshank according to Spesh - yes. They said ‘Yes, the new remotes can be fitted to other models of Creo's - These attach to the TCU (top tube display) via a split cable.
We should have these in stock around mid November (UK), and the parts number will be S216800011’. Hope this helps."
Quote 2:
"New handlebar remote buttons coming soon. SBC part # 98921-5710, allows you to adjust the power modes with ease, place buttons anywhere on your handlebar."
Attachments
sapidus
New Member
I just accidently ran across this and thought I'd post it. Evidently Specialized's answer to the extra water bottle mounting issue. Don't know anything else about it. On sale online at Specialized for 9.99 USD - without the cage The Wing is 4.99 USD.
Reserve Rack
The Reserve Rack is our tried-and-true device for carrying both inflation essentials and hydration in an aerodynamic position. It mounts at the rear of the saddle, and it's capable of holding a bottle. And when used with a Wing, it's capable of also holding an Airtool Road Mini Pump and up to two CO2 canisters.
Reserve Rack
The Reserve Rack is our tried-and-true device for carrying both inflation essentials and hydration in an aerodynamic position. It mounts at the rear of the saddle, and it's capable of holding a bottle. And when used with a Wing, it's capable of also holding an Airtool Road Mini Pump and up to two CO2 canisters.
FlatSix911
Well-Known Member
- Region
- USA
- City
- Silicon Valley
Link?
sapidus
New Member
Made for riders, by riders. | Specialized.com
From seasoned pros and weekend warriors, to kids and commuters—if you ride, we’re for you. We believe bikes have the power to change lives. This simple truth drives us to be—and do—better.
www.specialized.com
e-levity
Active Member
I use it all the time off-road, no issues. That's why it's there. Modern chains can deal with pretty extreme 1X chain lines.
(I'm currently using it with a 42t Narrow/Wide chainring, but it was fine with the 46t Praxis.)
Just keep your chain clean and lubed, and make sure the B-screw is properly adjusted.
SwiftySanders
Active Member
- Region
- USA
- City
- New York, NY
Install spacers for sure.
FlatSix911
Well-Known Member
- Region
- USA
- City
- Silicon Valley
It's best to keep your bike upright to keep air bubbles from forming in the hydraulic system.
If you have to lay the bike flat, then keep the brake lever reservoir above the calipers and pads.
Pad spacers are also a good idea if you remove the wheels to prevent the calipers from closing shut.
Do you ever put your bike upside down? 67% of you say it’s fine, and even the pros do it, so what's the problem?
Hands up if you’ve ever turned your bike upside down?
yes, it shows up on Mission Control.
RMK!
Well-Known Member
Yes, Mission Control under "Diagnose" - Device Updates" you will find the current version and available upgrades. Firmware updates need to be performed by a dealer.
Deacon Blues
Well-Known Member
I'm wondering if anyone has purchased a Planet 3 device to derestrict their Creo.
