Peddle Assist not working

Kitesurf2

New Member
I replaced the clutch in my Bafang G510 motor. When I put the motor back on the bike the pedal assist does not work. Throttle is working fine. I took the motor back off and checked that the wires inside the motor were connected correctly to the controller. Still no pedal assist.
Any ideas what the problem could be or what I should check next?

Do you have a PAS sensor on your bike's crank axle. That's what I'd check, making sure it's undamaged, properly mounted, and plugged in.

Double check all again.
The torque sensor is part of axle assembly that you installed the new clutch on... So follow and check that wiring well.
Then I'd unplug and reset all the connectors on the controller.

If your motor Is UART... You can use the programming software to check the torque sensor output
