Front Sprocket upgrade

jay p

New Member
Anyone find a larger front sprocket for their Himiway? Seems top speed could use better gearing.
Looking for something around 50 tooth or slightly larger.
Thanks for your inputs.
Jeff

Yes. It measures 104mm. I'm thinking the diameter of the 46t is 193mm. A 50t would seem to be 209mm. The rear wheel frame on the sprocket side is a very close fit. Forget a 52t at 217. Alternative would be stack the larger ring on the outboard of the crank bracket. Currently it is inboard.

Last edited:
Yes, chain angle is a concern. Impact on the lower gears if any.
I corrected my diameters on the 50t (209mm) and 52t (217mm) ring. Also it seems the thickness using my calipers is around 2mm. I haven't taken anything apart, but seems regular rings are around 4mm thickness.

Hi Jay! I signed up to this forum just to see if you were successful in changing the chainring? I was researching this mod for the same reasons. It looks like a cassette change to an 11 tooth gear would make a bigger difference but cost a lot more and be a bit more difficult to complete(though their is a great YouTube tutorial).

I ordered the 52 tooth chainring. It will be super close to the wheel frame but might work. The increased top speed from a 46 tooth to a 52 tooth might not help much, but a 50 tooth would have been useless I think.

Agree. When all installed, please share. The only thing besides that frame clearance is getting a few more links in the chain. I will likely use the top gear more than the lowest...
Thanks for taking the plunge!!

Wow Timpo! thanks for helping us figure all of this out. That video was super informative. The 11 tooth freewheel that would fit the Himiway looks like it is not very expensive but I read a review that said they might wear out fast and be more likely to cause the chain to pop off and possibly even bind the wheel which could have some catastrophic results. Do you think that is a likely problem or just worst case worrying? I don't want to be this guy:

Made the swap tonight. As we expected the teath of the chainring were going to rub on the frame. I was prepared to file the frame back a little for enough clearance but there are cables and ties right there also so I looked at placement on the outside of the crank. The Himiway comes with that guard plate on the outside anyway so there is a shoulder on the outside of the crank. The new chainring was thicker than the original one but when you combine the width of the guard the chainring bolts were perfect. So I rode it a little in high gear and wow! What an improvement! Between 20-30 mph the cadence is so much more comfortable. On a slight upgrade it was much easier to give the bike some help to stay around 27mph. I haven't added chain yet so no shifting into low gears so I couldn't see if the chainring moving over 1/4 inch causes the chain angle to make trouble. I will report back on that later. Here are some photos:


Attachments

  • IMG_3945.JPG
    290.5 KB · Views: 727
  • IMG_3946.JPG
    284.4 KB · Views: 715
  • IMG_3948.JPG
    244 KB · Views: 779
  • IMG_0939.JPG
    117.5 KB · Views: 705
WONDER NEWS!!!!
Plan B was to move the chain ring from the original position given clearance issues. Performance is a good step!!
Thanks for the pics...send a long order specs, info .....
Jeff

I've never replaced that front sprocket... does the crank have to all come out for the upgrade to the 52t?

Even though the himiway comes with the 46 tooth on the inside of the crank the 52 tooth has to mount on the outside to prevent contact with the frame going around the rear wheel. It fits great on the outside of the crank but I haven’t extended the chain yet so I can shift into the low gears and check how sharp the chain angle is. I hope to get the chain fixed in the next couple of days and be able to report on how the completed upgrade works.

Is it necessary though?

I can only speak from my experience (Juiced Bikes) but because the chain was too long, I actually shortened it. (128 links to 116 links)
I think so. The chain is stretched out fairly tight when it is on the 14 tooth sprocket. I don’t think it will even go over the large sprocket.

Apologies if I missed this in the thread, but what is the difference between the Deckas Round vs Deore?

Hi, I am trying to update my front chain ring on my Rize bike. Looks like most of the frames are made in the same factory in China so the actual name on the bike does not matter that much. I got stuck with the disassembling part of the process. Can anybody help me, how to remove the front sprocket? Any help is hugely appreciated!

Thank you for your reply, though the problem is that the chain ring itself is on the frame side of that protective ring it's bolted onto. So even if I will unscrew those five screws I have no way of removing the chain ring itself.

You're welcome.

Just keep in mind that this isn't always the case. Sometimes you will have to take the crank off, depending on the design on chain ring.

For example, something like this would not work, if you want to mount it inside.
As you can see, the holes are way out of diameter of the inner part of chain ring, in this case, you will have to take the crank off.
Bike Chain Ring Single Chainring 32T 34T 36T 38T 104 BCD Bike Narrow Wide  Chainrings for Bicycle Road Bike Mountain Bike BMX MTB Fixie Track Fixed,  Chainrings - Amazon Canada

But if you're getting a 52T Deckas ring, you will be mounting it outside anyways, so it wouldn't matter.

Also, the stock Himiway chain ring appears to be inside (I don't own himiway, I can only judge from photograph, but because of design on stock Himiway chain ring, you should be fine without taking off the crank.
Like many, I use this bike at the top end of the speed range on roadways. Not likely to ever do "real" trail riding. I just installed the 52t Deckas 4-bolt chain ring. As previously discussed, it WILL hit the frame lightly when replaced on the inside. My ring has an ever-so-slight warp where it touches on about 4 teeth and rides free the rest of the circumference. Plan A, I am going to look into ever so carefully tapping in the frame to allow clearance. Plan B would be taking a bit off those 4 teeth. I prefer a chain ring guard in place to avoid obvious catching of clothing.. Plan C is to mount the ring outside.

NOW, time to look for a chain guard with a 52t diameter and 4 bolt configuration.

update: took my beloved Dremel to grind a few thousands off the offending teeth. Many miles later NO ISSUE. It will make a notable change to lower gears.

ASIDE: I find the crank length/position to be short. I have to climb up to get seated only to feel like I lost the proper leg extension while peddling.

Last edited:
Even though the himiway comes with the 46 tooth on the inside of the crank the 52 tooth has to mount on the outside to prevent contact with the frame going around the rear wheel. It fits great on the outside of the crank but I haven’t extended the chain yet so I can shift into the low gears and check how sharp the chain angle is. I hope to get the chain fixed in the next couple of days and be able to report on how the completed upgrade works.

Hi, I appreciate all this info about the chainring upgrade. What did you determine about chain length or bend? I'd like to make this upgrade to my himiway too.

Guys...I have a Himiway Cruiser. I changed my freewheel from a 14 x 28 to an 11 x 34. I liked the difference and all worked OK. Then I changed my chainring from the stock 46T to a 52T. I couldn't mount it on the inside of the crank bracket like the 46T because it hit the frame. So I mounted it on the outside of the crank bracket where the guard usually mounts. And due to the 11 x 34 freewheel the chain was then too short to be able to shift successfully to the lowest freewheel 34T sprocket. I haven't tried a longer chain yet, but not liking the severe angle with the chainring on the outside of the bracket, I probably won't try a longer chain anyway. I really didn't like the looks of the severe chain angle also. It looked unsafe and likely to cause a problem. Then I tried a 50T chainring. The 50T hit the frame also if I tried to mount it the same as the 46T. Same issue with the severe chain angle also again. Now I've got the 11 x 34 freewheel and the stock 46T chainring again. I'm going to order a 48T chainring. 46T to 48T isn't much so I don't know if I'll even notice any difference, but a change is a change and I'd like to try and eliminate ghost pedaling. I'm hoping it will be able to mount on the inside of the crank bracket and not hit the frame and I'll still be able to use the guard on the outside. Another option I've been thinking about is changing the crank arms themselves. Stock Himiway Cruiser crank arms are supposed to be 170mm. I don't want to start having problems with pedal strikes or comfort but I think if it might be possible to swap to 175mm crank arms it might help reduce or limit ghost pedaling. Has anyone here tried that and what do y'all think?

Exactly..... a lot of words for exactly the concerns I had about trying to run the 52T chainring with the 11 x 34 freewheel. Chain control issues like the guy says. His conclusion...DON'T DO IT....which was also my conclusion. And I didn't do it. And like he says at the end, "If it ain't broke, don't fix it." I agree 100%. There's a few people on YT and in forums that seem like they know what they're talking about but really, you need absorb as much as you can and "take everything with a grain of salt" as the saying goes, and use common sense........🤔


Attachments

  • Capture Common Sense.JPG
    Capture Common Sense.JPG
    110.6 KB · Views: 124
